DONANIM ÖZELLİKLERİ
Arabirim• 9× 10/100 Mbps RJ45 Ports (8× 10/100 Mbps 802.3af/at PoE+ ports)
• AUTO Negotiation
• AUTO MDI/MDIX
Ağ Medyası• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
• EIA/TIA-568 100Ω STP (maximum 100m)
• 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
• EIA/TIA-568 100Ω STP (maximum 100m)
Fan SayısıFanless
Fiziksel Güvenlik KilidiYes
Harici Güç KaynağıExternal Power Adapter (Output: 53.5VDC / 1.31A)
Paket Yönlendirme Hızı1.3392 Mpps
PoE Portları (RJ45)• Standard: 802.3 af/at compliant
• PoE Ports: Ports 1–8
• Power Supply: 65 W
MAC Adres Tablosu2K
Jumbo Frame2 KB
Switching Kapasitesi1.8 Gbps
Boyutlar ( W X D X H )6.7 × 3.9 × 1.1 in (171 × 98 × 27 mm)
Maks. Güç Tüketimi• 3.6 (220/50 Hz. no PD connected)
• 77.08 (220/50 Hz. with 65 W PD connected)
Max Heat Dissipation• 12.28 BTU/h (no PD connected)
• 262.84 BTU/h (with 65 W PD connected)
YAZILIM ÖZELLİKLERİ
İletim MetoduStore-And-Forward
Gelişmiş Fonksiyonlar• Compatible With IEEE 802.3af/at Compliant PDs
• Extend Mode Button (Ports 1–4 and Ports 1–8, Up to 250 m PoE power supply and data transmission)
• Priority Mode Button (Ports 1–2)
• Isolation Mode Button (Ports 1–8)
• Mac Address Auto-Learning and Auto-Aging
• IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure for Half-Duplex Mode
DİĞERLERİ
SertifikaFCC, CE, RoHS
Paket İçeriği• TL-SF1009P
• Power Adapter
• Installation Guide
Ortam• Operating Temperature: 0–40 ℃ (32–104 ℉)
• Storage Temperature: -40–70 ℃ (-40–158 ℉)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% RH non-condensing
